Chronic Myelogenous Leukemia

Etiology

An increased incidence of CML has been reported among atomic bomb survivors; however, the predisposing risk factors are unknown.[1]

Epidemiology

CML has a worldwide annual incidence rate of 0.87 per 100,000 people, which increases to 1.52 per 100,000 in patients older than 70 years. CML has a slight predominance in men, and the median age at diagnosis is 56 years.[2] In the United States, the annual incidence rate between 2009 and 2013 was 1.4 and 2.2 per 100,000 for women and men, respectively.[3] Estimates for 2018 were 8490 new cases of CML and 1090 estimated deaths.[4]

Pathophysiology

The fusion oncoprotein BCR-ABL1 defines CML. Approximately 90% to 95% of patients with CML have a shortened chromosome 22 because of a reciprocal translocation t(9;22) (q34;q11.2) called the Philadelphia chromosome. The ABL1 gene encodes a nonreceptor tyrosine kinase on chromosome 9, and BCR is the breakpoint cluster region on chromosome 22. The translated oncoprotein, in most cases, is 210 kDa and called p210 BCR::ABL1. Alternative splicing yields p190 and p230 BCR::ABL1, which may lead to different presentations. This oncoprotein acts as a constitutively expressed defective tyrosine kinase. The downstream pathways affected include JAK/STAT, PI3K/AKT, and RAS/MEK, which are involved in cell growth, cell survival, inhibition of apoptosis, and activation of transcription factors.[5] The remaining patients have variant or complex translocations involving additional chromosomes detected by routine cytogenetics, or a cryptic BCR::ABL1 translocation detected by fluorescence in situ hybridization (FISH) or reverse transcriptase polymerase chain reaction (PCR).[6]

Histopathology

Chronic Phase

The peripheral blood smear shows leukocytosis with granulocytes at various stages of maturation. A bimodal distribution is present, with higher proportions of mature segmented neutrophils and myelocytes. Blast cells account for less than 2% of the white blood cells. Basophilia and eosinophilia are common. Significant dysplasia affecting greater than 10% of the granulocyte population is absent. Monocytosis may be present; however, monocytes usually account for less than 3% of the white blood cells. Platelets usually fall within the reference range, with a significant increase; thrombocytopenia is an uncommon finding.[7]

Bone marrow aspirate and biopsy show hypercellularity with marked granulocytic proliferation and a significant increase in myelocytes, although significant dysplasia should be absent (see Image: Chronic Myeloid Leukemia). Blasts are usually less than 5%. Erythroid precursors are considerably decreased, and the myeloid to erythroid ratio is increased. Megakaryocytes may be reduced, normal, or increased. About half of the specimens show megakaryocyte proliferation. The megakaryocytes in CML show a small, hypolobate dwarf morphology. The biopsy shows immature granulocytes within a thickened band of 5 to 10 cells along the trabeculae of bone. The normal distribution site of immature granulocytes is adjacent to bone trabeculae; however, this layer is usually 2 to 3 cells thick. The bone marrow may also show increased reticulin fibrosis.[8]

Accelerated Phase

The peripheral smear may or may not show increased blasts (10% to 19%). The bone marrow aspirate and biopsy will show changes similar to those of chronic phase CML, with increased blasts (10% to 19%), possible granulocytic dysplastic changes, and increased reticulin and collagen fibrosis.[9]

Blast Phase

The peripheral smear and/or bone marrow aspirate will show more than 20% blasts, or there will be an extramedullary blast proliferation. Most cases will show blasts with myeloid differentiation; however, other lineages or combinations may be present, including lymphoblasts. Extramedullary proliferation is most commonly seen in the skin, lymph nodes, bone, and the central nervous system (CNS).[10]

History and Physical

Approximately half of patients with CML are asymptomatic and are diagnosed after routine complete blood count testing. Most patients are in the chronic phase of CML. Chronic phase CML most often presents with symptoms related to anemia and splenomegaly. Symptomatic anemia includes fatigue and malaise. Splenomegaly may cause a mass effect, resulting in early satiety, left upper quadrant fullness, or pain. CML may also cause thrombocytopenia or platelet dysfunction, resulting in bleeding; thrombocytosis, resulting in thrombosis or priapism; basophilia, resulting in histamine release; and upper gastrointestinal tract ulcers. Symptoms such as headaches, bone pain, fever, joint pain, bleeding, infections, and lymphadenopathy become more common as CML progresses into the accelerated phase or blast phase.[6]

The physical examination should include assessment of the spleen size by palpation, measured in centimeters below the costal margin.[11][12] ] Splenomegaly is the most common physical examination finding in patients with CML. In more than half of patients, the spleen extends more than 5 cm below the left costal margin at the time of diagnosis. A very large spleen is usually a heralding sign of disease transformation into acute blast crisis. Hepatomegaly may also be found because extramedullary hematopoiesis occurs in the spleen. Physical examination findings may also include signs of hyperviscosity. Fundoscopy may show papilledema, venous obstruction, and hemorrhages.

Evaluation

Initially, if CML is suspected, cytogenetic testing, fluorescence in situ hybridization, or reverse transcription PCR can be performed on peripheral blood to detect the Philadelphia chromosome or the BCR::ABL1 oncoprotein. At the time of diagnosis, laboratory blood testing should include a complete blood count with differential, chemistry panel, hepatitis panel, and quantitative PCR for BCR::ABL1. A baseline bone marrow aspirate and biopsy should be performed with cytogenetics. Quantitative PCR should be repeated every 3 months after initiation of therapy. After BCR::ABL1 is less than or equal to 1% (international scale), quantitative PCR should continue for 2 years, then every 3 to 6 months thereafter.

If chronic phase CML is established, additional evaluation includes determining the risk score using Sokal et al or Hasford et al risk calculations before selecting first-line therapy.[6]

• The Sokal risk calculation uses age, spleen size, platelet count, and percentage of myeloblasts in peripheral blood to determine the risk group [11]
• The Hasford risk calculation uses age, spleen size, platelet count, and percentage of blasts, eosinophils, and basophils in the peripheral blood to determine the risk group [12]

If accelerated- or blast-phase CML is diagnosed, or if CML progresses from chronic phase, additional testing should include flow cytometry to determine lineage, mutational analysis, and histocompatibility testing if allogeneic hematopoietic stem cell transplant (HSCT) is being considered. Additional bone marrow cytogenetics and mutational analysis should be considered if there is failure to meet response milestones or any evidence of hematologic or cytogenetic relapse.[6]

Treatment / Management

The US Food and Drug Administration has approved 4 commercially available tyrosine kinase inhibitors for first-line treatment of chronic phase CML: first-generation imatinib and second-generation dasatinib, nilotinib, and bosutinib.

Dosing

• Imatinib: 400 mg daily [13][14]
• Bosutinib: 500 mg daily [15]
• Dasatinib: 100 mg daily [16]
• Nilotinib: 300 mg twice a day [17]
(A1)

For chronic phase CML with an intermediate- or high-risk score, second-generation tyrosine kinase inhibitors (bosutinib, dasatinib, nilotinib) as first-line therapy may confer additional benefit over imatinib.[15][16][17] Ponatinib, a third-generation tyrosine kinase inhibitor dosed at 45 mg daily, is a third-line treatment option in chronic-phase CML for patients who have not responded to multiple tyrosine kinase inhibitors and for those with the T315I mutation.[18](A1)

Advanced CML (accelerated or blast phase) has additional therapeutic considerations. Second- or third-generation tyrosine kinase inhibitor therapy should be initiated to reduce the CML burden and be considered for early allogeneic HSCT.[6] Omacetaxine is a chemotherapeutic agent that is an additional treatment option in cases refractory to tyrosine kinase inhibitor therapy that advanced from chronic phase CML.[19] Allogeneic HSCT should be considered in patients with chronic phase CML who are resistant to tyrosine kinase inhibitor therapy and in patients with advanced CML.[6][20] Clinical trial participation should be considered for all patients.

Differential Diagnosis

Differentiating CML from other causes of granulocytic leukocytosis, such as infections or drugs, is necessary. Most causes of reactive leukocytosis have a white blood cell count of less than 50 × 10?/L and show toxic changes, such as toxic granulation and Döhle bodies. Basophilia is also absent. Other myeloproliferative disorders, such as chronic neutrophilic leukemia (CNL) and polycythemia vera, may present with leukocytosis and thrombocytosis. CNL and polycythemia vera lack the BCR::ABL1 fusion gene. CNL is rare and presents with mature segmented neutrophilia, lacking bimodal leukocytosis with myelocytes.[6]

Pertinent Studies and Ongoing Trials

A search of ClinicalTrials.gov showed 221 active, interventional CML trials, with 125 recruiting. These trials are highly variable, with study topics including novel drugs, optimization of current treatment modalities, potential combination drug regimens, the efficacy of treatment discontinuation, and immunotherapy. Ongoing trials of note include the randomized international phase 3 study Evaluating Nilotinib Efficacy and Safety in Clinical Trials-Newly Diagnosed Patients (ENESTnd),[17] and the phase 3 study Results of Efficacy and Safety of Radotinib Compared with Imatinib in Newly Diagnosed Chronic Phase Chronic Myeloid Leukemia (RERISE).[21]

Other pertinent studies include trials that supported the first-line treatment with imatinib and dosing including the CML Study 4,[13] the Tyrosine Kinase Inhibitor Optimization and Selectivity (TOPS) study,[14] and the International Randomized Study of Interferon and STI571 trial (IRIS).[22] Important trials concerning the efficacy and dosing of the second-generation FDA-approved tyrosine kinase inhibitors include the Bosutinib Efficacy and Safety in Newly Diagnosed CML trial (BELA),[15] the Bosutinib Versus Imatinib in Adult Patients With Newly Diagnosed Chronic Phase Chronic Myelogenous Leukemia trial (BFORE),[23] Dasatinib Versus Imatinib Study in Treatment-Naive Chronic Myeloid Leukemia Patients trial (DASISION),[16] and the ENESTnd study.[17] Pertinent studies and ongoing trials assessing tyrosine kinase inhibitor therapy discontinuation efficacy and candidate recommendations include the imatinib discontinuation study (STIM1),[24] Evaluating Nilotinib Efficacy and Safety in Clinical Trials: Treatment-Free Remission study (ENESTfreedom),[25] Imatinib Suspension and Validation study (ISAV),[26] and Discontinuation of Tyrosine Kinase Inhibitor Therapy in Chronic Myeloid Leukaemia trial (EURO-SKI).[27]

Treatment Planning

Any of the 4 FDA-approved tyrosine kinase inhibitors is highly effective in treating chronic phase CML. In selecting front-line therapy, a patient’s age, comorbidities, and tyrosine kinase toxicities must be taken into account. For patients with chronic phase CML, the use of the Sokal or Hasford risk stratification scores helps predict outcomes and guide the choice of first-line tyrosine kinase inhibitor.[11][12] For chronic phase CML with intermediate- or high-risk scores, second-generation tyrosine kinase inhibitors (bosutinib, dasatinib, nilotinib) may have the additional benefit over imatinib in achieving response milestones.[15][16][17][28]

At baseline, all patients should undergo bone marrow examination and cytogenetic analysis to monitor treatment response. The patient should be monitored at 3, 6, and 12 months after starting therapy using cytogenetic and molecular studies such as PCR performed on peripheral blood.[29] The primary goal in chronic-phase CML treatment is to achieve a complete cytogenetic response by 12 months after initiation of tyrosine kinase inhibitor therapy. Response milestones include complete hematologic response, cytogenetic response, and major molecular response.[6] A complete hematologic response is defined as complete normalization of peripheral blood counts, with a leukocyte count below 10 x 109/L and a platelet count below 450 x 109/L; the absence of myelocytes, promyelocytes, and blasts; and the absence of signs and symptoms of the disease, including the disappearance of a palpable spleen.[30] A complete cytogenetic response shows no Philadelphia-positive metaphases, and a major molecular response is defined as BCR-ABL1 transcripts of less than 0.1% on the international scale.[31]

The European Leukemia Net (ELN) 2013 criteria can serve as a guide for monitoring failure or suboptimal response to first- or second-line therapy. These criteria evaluate patients with chronic phase CML at 3, 6, and 12 months, and then at any subsequent follow-up; the optimal response is defined by PCR as BCR-ABL1 transcripts of less than or equal to 10%, less than 1%, and less than or equal to 0.1%, respectively. Alternatively, if quantitative PCR is not available, cytogenetics can detect the Philadelphia chromosome but is not useful for cryptic BCR-ABL1. If the optimal response is not achieved, there is a warning response group and a failure response group. In the warning group, consideration of dose escalation of imatinib or changing tyrosine kinase inhibitors is warranted.[32] However, if an optimal response is not achieved at 3 months, studies show that most patients achieve an optimal response at 6 months without changes in therapy, with a similar prognosis.[33] Another consideration is patient compliance; poor adherence is a significant contributor to treatment failure and loss of complete response.[34] In high-risk cases, at the time of diagnosis or in the event of treatment failure despite good patient compliance, tyrosine kinase inhibitor therapy should be changed. The patient should be evaluated for the possibility of allogeneic HSCT.[6]

In the event of tyrosine kinase inhibitor resistance, analysis of the BCR-ABL1 mutational profile may be useful for selecting second- or third-line therapy. The T315I mutation has been shown to confer resistance to imatinib and all second-generation tyrosine kinase inhibitors. In these patients, ponatinib should be considered.[18] In cases of Y253H, E255K/V, or F359C/V mutations, dasatinib or bosutinib may have better responses, and in cases of V299L and F317L mutations, nilotinib may have promising outcomes.[6]

For accelerated- or blast-phase CML, treatment considerations include evaluation for allogeneic HSCT; assessment of whether the advanced phase presented while the patient was on or off tyrosine kinase inhibitor therapy; comorbidities; age; prior therapy; and analysis of the BCR-ABL1 mutation profile. Chemotherapy is often required in advanced CML to reduce disease burden and prepare for allogeneic HSCT.[19][20][32]

In patients who achieve a long-term deep molecular response to therapy, discontinuation of tyrosine kinase inhibitors may be considered. Treatment-free remission can be achieved in approximately 40% to 60% of the low-risk to intermediate-risk patients. Characteristics that predict treatment-free remission include low Sokal risk, no history of tyrosine kinase inhibitor resistance, and a duration of tyrosine kinase inhibitor use greater than 5 years. Most relapses occur within the first 6 months after discontinuation; molecular monitoring should be performed monthly for the first year and every 6 to 12 weeks thereafter. If molecular relapse occurs, the tyrosine kinase inhibitor therapy should be re-initiated.[35]

Toxicity and Adverse Effect Management

Most patients will develop mild to moderate adverse events early in tyrosine kinase inhibitor therapy, and most resolve spontaneously or are well controlled. Adverse events are divided into 4 grades based on severity.

• Grade 1 adverse events do not require a change in tyrosine kinase inhibitor therapy; however, specific treatment may be needed.
• Grade 2 adverse events involve withholding therapy until severity decreases or continuing therapy if symptoms improve with monitoring. If a grade 2 adverse event is recurrent, dose reduction should be considered.
• Grade 3 adverse events involve withholding therapy until severity decreases and then restarting at a lower dose or withholding therapy until symptoms decrease to grade 1 or less before resuming the prior dosage. If grade 3 adverse events do not resolve or are recurrent, the tyrosine kinase inhibitor should be changed.
• Grade 4 events should involve switching tyrosine kinase inhibitor therapy when possible.[36]

Vascular System

Ischemic heart disease, ischemic cerebrovascular events, and peripheral arterial occlusive disease have correlations with nilotinib and ponatinib. Higher dosing has been associated with a higher risk of these events. Cardiovascular risk should be evaluated before therapy with these agents begins and closely monitored during treatment. Risk assessment and monitoring should include hemoglobin A1C, lipid profile, and serum creatinine. These drugs should be used with caution in patients with a high risk for vascular disease.

Cardiac Function

Ponatinib has an associated incidence of heart failure. Monitoring cardiac function should be mandatory for patients receiving ponatinib.

Cardiac Rhythm Alterations

Tyrosine kinase inhibitors have the potential to alter the QT interval. Nilotinib has the highest incidence of QT interval prolongation. Ponatinib is associated with QT interval shortening. Electrocardiogram at baseline and periodically in select patients on any tyrosine kinase inhibitor with QT interval prolongation, and in those on ponatinib. Nilotinib should be avoided in patients with a high risk for arrhythmias or when other drugs that may alter the QT interval are being administered. Potassium and magnesium levels should be replete before initiation of tyrosine kinase inhibitor therapy in all cases.

Pulmonary System

Pleural effusions can occur with all tyrosine kinase inhibitors but most commonly occur with dasatinib. Patients with preexisting lung injuries, chronic lung disease, congestive heart failure, and hypertension are at the highest risk of developing pleural effusions. Caution is necessary if patients develop a cough, shortness of breath, or chest pain during therapy, and chest radiography must be obtained in such cases. Reports also describe pulmonary hypertension with dasatinib use. If pulmonary hypertension is suspected, dasatinib should be stopped immediately.

Hepatobiliary System

Hepatotoxicity is common in all tyrosine kinase inhibitors. Ponatinib has the highest risk of developing high-grade increases in transaminases. Substances that alter liver metabolism via cytochrome P450 and acetaminophen should be used with caution or avoided entirely. Prompt treatment with glucocorticoids in severe cases of hepatotoxicity can assist hepatic recovery.

Hyperglycemia

Nilotinib has been shown to induce hyperglycemia in patients with and without. Fasting glucose and hemoglobin A1c require monitoring.

Hypercholesterolemia

Nilotinib is associated with increases in low-density lipoprotein cholesterol. Hypertriglyceridemia has been reported with ponatinib. If persistent high-risk hypercholesterolemia develops, appropriate statin initiation may be warranted.

Other Endocrinopathies

Hypophosphatemia and hypocalcemia have been reported with imatinib, nilotinib, and dasatinib. Phosphate, calcium, and vitamin D levels should be tested at baseline and then monitored. Hypothyroidism may also develop and is treated effectively with hormone replacement.

Myelosuppression

Myelosuppression is common with all tyrosine kinase inhibitors but is usually limited to the first few weeks to months of therapy. Leukocytes, erythrocytes, and platelets can all be affected; therefore, close monitoring of blood counts and response is necessary to avoid infection and bleeding. Tyrosine kinase inhibitor interruption, dose reduction, and supportive treatment with blood products are considerations based on the severity of cytopenias, the specific tyrosine kinase inhibitor, and the disease phase. Any nutritional deficiencies should be corrected before therapy is initiated.

Gastrointestinal System

Nausea, diarrhea, abdominal pain, and vomiting are frequent adverse effects related to tyrosine kinase inhibitors. Diarrhea is especially significant with bosutinib and often requires dose interruption or dose reduction. Patients can take their medication with meals to avoid nausea and vomiting. In severe cases, antiemetic or antidiarrheal medication can be administered, and hydration status should be closely monitored. Gastrointestinal bleeding has been reported with dasatinib. Reports describe increased lipase levels and pancreatitis with nilotinib and ponatinib..

Dermatologic System

Rash development is common with all tyrosine kinase inhibitors. Most cases are dose-related and self-limited. Management can comprise topical therapies, antihistamines, and short courses of systemic corticosteroids. In severe cases, prednisone merits consideration with the gradual reintroduction of the offending tyrosine kinase inhibitor.

Kidney Injury

Monitoring for tumor lysis syndrome should be done from the outset of treatment with all tyrosine kinase inhibitors. Otherwise, the development of acute kidney injury may result from imatinib therapy. Dasatinib and bosutinib have also been associated with acute kidney injury but at lower incidence rates. Serum creatinine levels require monitoring in these patients, and caution is warranted in those with renal insufficiency. Other commonly reported adverse events include myalgia, bone pain, ophthalmological changes, and headache.[6][36]

Staging

CML staging is determined by the disease phase, which includes the chronic, accelerated, and blast phases. The chronic phase has fewer than 10% blasts, is asymptomatic to mildly symptomatic, and responds to tyrosine kinase inhibitor therapy.

The World Health Organization (WHO) defines accelerated phase CML as having 1 or more of the following criteria:

• Persistent or increasing white blood cell count (greater than 10 x 10⁹/L) unresponsive to therapy
• Persistent or increasing splenomegaly unresponsive to therapy
• Persistent thrombocytosis (greater than 1000 x 10⁹/L) unresponsive to therapy
• Persistent thrombocytopenia (less than 100 x 10⁹/L)
• Greater than or equal to 20% basophils in peripheral blood
• 10% to 19% blasts in peripheral blood or bone marrow (without extramedullary blast proliferation)
• Additional chromosomal abnormalities in Philadelphia chromosome-positive cells at diagnosis
• Any new clonal chromosomal abnormality in Philadelphia chromosome-positive cells during therapy

The WHO also considers resistance to tyrosine kinase inhibitors to be provisional criteria for determining accelerated-phase CML. Blast phase CML is defined by greater than or equal to 20% blasts in the peripheral blood or bone marrow or extramedullary blast proliferation.[9]

Prognosis

Before introducing imatinib, most CML cases progressed to the blast phase, and death occurred in under 5 years. Since tyrosine kinase inhibitors have been the first-line therapy for CML, the 5-year survival has risen from 33% to over 90%. The 10-year survival has risen from 11% to 84%, and complete cytogenetic response occurs in 70% to 90% of patients. Individuals diagnosed with chronic phase CML are expected to reach normal or near-normal life expectancy.[28]

Cytogenetic analysis for additional abnormalities, in addition to the classic translocation, may be important for prognostic information. Previously, any additional chromosomal abnormalities were considered a risk for disease progression, tyrosine kinase inhibitor resistance, and worse prognosis. However, results from studies have shown that single additional chromosomal abnormalities, including trisomy 8, loss of the Y chromosome, and an extra copy of the Philadelphia chromosome, do not affect survival. The presence of 2 or more additional chromosomal abnormalities or a single additional chromosomal abnormality involving i(17)(q10), loss of chromosome 7 or deletion of 7q, or 3q26.2 rearrangements is a poor prognostic indicator.[37]

The BCR::ABL1 mutational analysis may also impact prognosis. The T315I mutation was the first mutation discovered in association with the development of tyrosine kinase inhibitor resistance. More than 100 point mutations in the BCR::ABL1 oncogene have been isolated from patients with imatinib-resistant disease. These mutations may influence treatment planning in patients with first-line tyrosine kinase inhibitor–resistant disease.[38] The future prognostic evaluation may include sequencing for mutations involving known cancer genes, such as IKZF1, RUNX1, ASXL1, BCORL1, and IDH1. These mutations were found in patients who underwent sequencing at the blast-phase of CML.[39]

Complications

Complications of CML can include:

• Hepatomegaly or splenomegaly
• Worsening anemia
• Changes in platelet count resulting in clotting or bleeding complications
• Recurrent infections
• Bone pain
• Fever
